New 2026 DOEPKER 55 Ton Tri-axle Traveling Axle Trailer For Sale

VERNON GENE'S - El Paso

$111,550

Description

$111,500.00 PLUS FET - Concentrated Load (lower deck): 55 Ton - Hydraulic Roller Option, Lift Capacity: approx. 14,700lb per roller at 2,500 psi cylinder pressure - 7 degree loading angle, 13 degree max tilt angle based on 8'6" wide model, 60" spread on 245/70R17.5 tires - 7.5 degree loading angle, 13 degree max tilt angle based on 8'6" wide model, 72" spread on 245/70R17.5 tires - 7 degree loading angle, 14 degree max tilt angle based on 9' and 10' wide models, 60" spread on 245/70R17.5 tires - 8 degree loading angle, 14 degree max tilt angle based on 9' and 10' wide models, 60" spread on 255/70R22.5 tires - Hinge down upper coupler plate operated with air operated lock pin - Live roll at rear of gooseneck and at front of main deck - Heavy Duty 6" bore x 3" rod x 190" stroke cylinder designed to be fully closed when trailer in transport position

Specifications
